HKD DOMO-DW-FL-K

  • Use in lining pipe provided by the customer or WU concrete core drilling (white tank)
Dealer search
Pressing water

Technical details

  • Tested in accordance with FHRK test basis GE 101 (No. G 30 322-2-6) - FHRK 40 LD10
  • Tight against pressing water (40 mm sealing width)
  • Radon-tight - in accordance with FHRK data sheet MB 101. Meets the requirements for radon precaution areas
  • Installation from the side facing away from the pressure
  • All metal parts made of stainless steel 1.4301 (V2A/Inox 304), optionally 1.4571 (V4A/Inox 316)
  • Seal material EPDM solid rubber, optionally NBR
  • Gas-tight

Areas of use

  • Use in lining pipe provided by the customer or WU concrete core drilling (white tank)

Product benefits

  • The HKD DOMO-DW-FL-K is characterized by its robust craftsman quality.
  • The design with large ring for absorbing pressure loads on one side and for axial fixing.

  • All metal parts made of stainless steel 1.4301 (V2A/Inox 304), optionally 1.4571 (V4A/Inox 316)
  • Seal material EPDM solid rubber, optionally NBR
