Curaflex® Quick In A
- Sealing of penetrations
- Use in lining pipe provided by the customer or WU concrete core drilling (white tank)
- Hinged, for already installed pipes
Curaflex® Quick In A
added to
.
Curaflex® Quick In A
removed from
.
Technical details
- Tested in accordance with FHRK test basis GE 101 (No. G 30 322-2-1) - FHRK 27 D01
- Gas and water-tight
- Radon-tight - in accordance with FHRK data sheet MB 101, meets the requirements for radon precaution areas
- Angles of the service pipes up to 8° possible
- Absorption of axial movements
- single sealing
Areas of use
- Sealing of penetrations
- Use in lining pipe provided by the customer or WU concrete core drilling (white tank)
- Hinged, for already installed pipes
Product benefits
- Large sealing areas
- Permanently tight without retensioning (maintenance-free)
- higher sealing performance of the gasket insert thanks to DPS and DOYMA-Grip
- Watertight welded bolts
- with quick-release fastener (up to DN 500), for secure and immovable closure
- Can be retrofitted around the existing pipe
- Can be used for double/element walls
- www.doyma.de
- Split frame rings: asymmetrically profiled steel rings (DPS up to KB/DN 350), with quick-release fastener (up to DN 500), ggv corrosion protection coating; optionally made of stainless steel 1.4301 (V2A) or 1.4571/1.4404 (V4A)
- Split rubber seal with stepped cut: Elastomer, 27 mm thick EPDM gaskets (DOYMA-Grip), optionally EPDM-TW, NBR (fuel/oil resistant) or silicone (high temperature resistant) or FPM (chemical resistant)
