Curaflex® 3001
- Recess for penetrations
- Use in structures structures to be built
- For use with liquid applied waterproofing materials (black tank)
- with adhesive flange according to DIN 18533
Curaflex® 3001
added to
.
Curaflex® 3001
removed from
.
Technical details
- Gas-tight against soil gases with waterproofing in contact with the ground
- Radon proof - according to FHRK leaflet MB 101
- also available in split version
- Tested in accordance with FHRK test basis GE 102 (No. G 30 322-2-9)
Areas of use
- Recess for penetrations
- Use in structures structures to be built
- For use with liquid applied waterproofing materials (black tank)
- with adhesive flange according to DIN 18533
Product benefits
- Optimally designed inner wall to accommodate DOYMA sealing systems and house entries
- Dimensionally stable and durable special fiber cement
- Expansion coefficient of the material corresponds to that of concrete
- Homogeneous connection to the concrete
- optimum connection thanks to special fiber cement flange
- with adhesive flange for on-site application of a thick coating (KMB/PMBC) for pressing water (W2.1-E)
- with adhesive flange for the on-site application of a mineral sealing slurry (MDS) or a liquid plastic (FLK) in the event of non-pressing water (W1-E or W3-E)
- with adhesive flange for the on-site application of a fresh concrete composite foil (FBV)
- Special fiber cement
- Special fiber cement fixed flange as adhesive flange according to DIN 18533
- Delivery incl. glass fiber fabric for KMB/PMBC
