Curaflex Nova® Uno/MS

  • Sealing of penetrations
  • Use in lining pipe provided by the customer or WU concrete core drilling (white tank)
  • with additional shrink technology
  • Ideal for flexible cable conduits
Dealer search
Pressing water
Non-pressing water

Technical details

  • Tested in accordance with FHRK test specification GE 101 (No. G 30 322-2-5) (here only for the Curaflex Nova® Uno sealing insert) - FHRK 40 LD10
  • Gas and water-tight
  • Radon-proof - in accordance with FHRK data sheet MB 101
  • with shrink technology

Areas of use

  • Sealing of penetrations
  • Use in lining pipe provided by the customer or WU concrete core drilling (white tank)
  • with additional shrink technology
  • Ideal for flexible cable conduits

Product benefits

  • with ITL system for optimum contact pressure - can also be installed with a cordless screwdriver
  • no relevant mechanical forces are exerted on the cable thanks to the shrink technology
  • ideal for corrugated pipes or medium-voltage cables where no mechanical forces may/can act on the cable (thin-walled "ribs" or similar)
  • Permanently tight without retensioning (maintenance-free)
  • higher sealing performance of the sealing insert thanks to DOYMA-Grip

Downloads

  • Installation situation
